Desigco CLS-XRay6030 is a high-power, large-aperture X-Ray system.
Desigco CLS-XRay6030 is specifically engineered to detect broken needles in subcutaneous tissues of meat.
It effectively inspects pork neck and other raw meats, making it ideal for hog slaughtering, pork processing, and other meat product safety applications.
AI-Powered Analysis: Employs advanced AI algorithms to accurately distinguish between broken needles and bone structures in pork.
Multi-Purpose Detection: Capable of identifying various foreign objects beyond needles, enhancing overall product safety.
User-Friendly Operation: Guided auto-learning enables quick product setup without prior experience, ensuring high precision.
Flexible Connectivity: Supports 4G wireless and wired networks for remote support and automatic fault reporting.
Robust System Architecture: Server-grade Linux OS provides virus immunity and data protection during power interruptions.
Easy Maintenance: Separable conveyor system allows direct water cleaning for convenient hygiene management.
Industrial Reliability: Double heat cycle design supports continuous 7×24 operation in demanding environments.
Enhanced Safety: Exceeds international radiation standards with safety interlock monitoring.
Model
CLS-XRay6030
Product Dimensions
Max Width: 600mm； Max Height: 300mm
Product Weight
Max Weight: 30kg
Conveyor Belt Speed
5–60m/min
Conveyor Height
800±50mm
X-Ray Power
380W/480W (optional)
Detector Size
0.4mm high-sensitivity receiver
Operating System
Linux
HMI(Human-Machine Int.)
17-inch industrial touchscreen
Software
Desigco X-Ray Inspection System
Radiation Protection
≤1 μSv/h, built-in leakage safety interlock
Power Supply
220VAC, 50–60Hz
Temperature & Humidity
Ambient temperature -10 — +45°C, relative humidity 30%-85%, built-in industrial air conditioning
Equipment Material
304 stainless steel
Ingress Protection (IP) Rating
Whole machine IP54, conveyor unit IP66
Detection Sensitivity (Unloaded)
Metal ball: φ0.3mm; Metal wire: φ0.2x2mm; Ceramic ball: φ0.7mm; Glass ball: φ0.8m
